Displacement 149.6ml
Engine Single Cylinder
Bore & Stroke 57.4×57.8
Cooling System Air Cooled
Compression Ratio 9.2:1
Fuel feed 90#
Max Power( Kw/rpm) 6.3/7500
Max Torque(N.M/rpm)  9.2/5500
Max Speed 85 kmph
Ground clearance 130 mm
Fuel consumption 2.5L/100KM
Drive Train CVT
Ignition CDI
Transmission Belt
Fuel tank capacity 6L
Starting System Electric+kick start
Front Brakes Disc brake
Rear Brake Drum brake
Front suspension Hydraulic Suspension
Rear suspension 2 Hydraulic Suspension
Front wheels Alum 120/70-12
Rear wheels Alum 120/70-12
Wheel Base 1340 mm
Seat Height 840 mm
Payload 150kg
Net Weight 113kg
Gross Weight 133kg
Packing type Steel + Carton
Packing size 1850*570*860 mm
20' container 24 units
40' HQ container 75 units
