Displacement 124.6
Engine 1 Cylinder, 4 Stroke
Bore & Stroke 52.4×57.8
Cooling System Air Cooled
Compression Ratio 9.2:1
Fuel feed 90#
Max Power( Kw/rpm) 5.6/7500
Max Torque(N.M/rpm)  7.8/4000
Max Speed 80 kmph
Ground clearance 110 mm
Fuel consumption 2.4L/100KM
Drive Train CVT
Ignition CDI
Transmission Belt
Fuel tank capacity 5L
Starting System Electric+kick start
Front Brakes Disc brake
Rear Brake Drum brake
Front suspension Hydraulic Suspension
Rear suspension 2 Hydraulic Suspension
Front wheels alum 120/70-12
Rear wheels alum 120/70-12
Wheel Base 1310 mm
Seat Height 780 mm
Payload 150kg
Net Weight 105kg
Gross Weight 125 kg
Packing type Steel + Carton
Packing size 1700×570×860mm
20' container 26 units
40' HQ container 84 units
