Displacement 49.5ml
Engine 1 Cylinder, 4 Stroke
Bore & Stroke 39×41.5
Cooling System Air Cooled
Compression Ratio 10.5:1
Fuel feed 90#
Max Power( Kw/rpm) 2.5/7500
Max Torque(N.M/rpm)  2.8/5500
Max Speed 50 kmph
Ground clearance 105 mm
Fuel consumption 2.0L/100KM
Drive Train CVT
Ignition CDI
Transmission Belt
Fuel tank capacity 5L
Starting System Electric+kick start
Front Brakes Disc brake
Rear Brake Drum brake
Front suspension Hydraulic Suspension
Rear suspension 1 Hydraulic Suspension
Front wheels steel 100/90-10
Rear wheels steel 100/90-10
Wheel Base 1290 mm
Seat Height 780 mm
Payload 75kg
Net Weight 87 kg
Gross Weight 107 kg
Packing type Steel + Carton
Packing size 1630×570×860mm
20' container 26 units
40' HQ container 87 units
