Displacement 124.04ml
Engine 1 Cylinder,4 stroke
Bore & Stroke 56.5×49.5mm
Cooling System Air Cooled
Compression Ratio 9.0:1
Fuel feed 90#
Max Power( Kw/rpm) 7.8/8500
Max Torque(N.M/rpm)  9.5/7000
Max Speed 85 kmph
Ground clearance 140 mm
Fuel consumption 2.1L/100KM
Ignition CDI
Transmission chain
Fuel tank capacity 12L
Starting System Electric+kick start
Front Brakes Disc brake
Rear Brake Drum brake
Front suspension Hydraulic Suspension
Rear suspension Hydraulic Suspension
Front wheels Alum 2.75-18
Rear wheels Alum 3.00-18
Wheel Base 1295 mm
Payload 150kg
Net Weight 108kg
Gross Weight 128kg
Packing type Steel + Carton
L*W*H 1980*725*1130mm
Packing size  1800*460*860mm
20FT quantity 30units
40HQ quantity 96units
